TUBES
Structural Tubes
Σωλήνες κατασκευών
Dimensions
Cross section
Weight
D (mm)
T (mm)
F (cm²)
G (kg/m)
26.9 (in 3/4)
1.0
0.81
0.64
1.2
0.97
0.76
1.5
1.20
0.94
2.0
1.56
1.23
2.5
1.92
1.50
33.7 (in 1)
1.0
1.03
0.81
1.2
1.23
0.93
1.5
1.52
1.19
2.0
1.99
1.56
2.5
2.45
1.92
42.4 (in 1
1/4)
1.0
1.30
1.02
1.2
1.55
1.22
1.5
1.93
1.51
2.0
2.54
1.99
2.5
3.13
2.46
3.0
3.71
2.91
48.3 (in 1
1/2)
1.0
1.49
1.17
1.2
1.78
1.39
1.5
2.21
1.73
2.0
2.91
2.28
2.5
3.60
2.82
3.0
4.27
3.35
4.0
5.57
4.41
60.3 (in 2)
1.0
1.86
1.46
1.2
2.23
1.75
1.5
2.77
2.18
2.0
3.66
2.88
2.5
4.54
3.56
3.0
5.40
4.24
4.0
7.07
5.59
76.1 (in 2
1/2)
1.5
3.52
2.76
2.0
4.66
3.65
2.5
5.78
4.54
3.0
6.89
5.41
4.0
9.06
7.17
5.0
11.2
8.77
88.9 (in 3)
1.5
4.12
3.23
2.0
5.46
4.29
2.5
6.79
5.33
3.0
8.10
6.36
4.0
10.7
8.43
5.0
13.2
10.3
101.6 (in 3
1/2)
2.0
6.26
4.91
2.5
7.78
6.11
3.0
9.29
7.29
4.0
12.3
9.70
5.0
15.2
11.9
6.0
18.02
14.15
114.3 (in 4)
2.0
7.06
5.54
2.5
8.78
6.89
3.0
10.49
8.23
4.0
13.9
11.00
5.0
17.2
13.5
6.0
20.41
16.03
139.7 (in 5)
2.5
10.78
8.46
3.0
12.88
10.11
4.0
17.1
13.5
5.0
21.2
16.6
6.0
25.20
19.78
168.3 (in 6)
3.0
15.58
12.23
4.0
20.65
16.21
5.0
25.7
20.1
6.0
30.59
24.02
Dimensions
Static data
D (mm)
T (mm)
I (cm⁴)
R (cm³)
Z (cm)
26.9 (in 3/4)
1.0
0.68
0.92
0.51
1.2
0.80
0.91
0.60
1.5
0.97
0.90
0.72
2.0
1.22
0.883
0.91
2.5
1.44
0.87
1.07
33.7 (in 1)
1.0
1.37
1.16
0.82
1.2
1.62
1.15
0.96
1.5
1.97
1.14
1.17
2.0
2.51
1.12
1.49
2.5
3.00
1.11
1.78
42.4 (in 1
1/4)
1.0
2.79
1.46
1.32
1.2
3.30
1.46
1.56
1.5
4.04
1.45
1.90
2.0
5.19
1.43
2.45
2.5
6.26
1.41
2.95
3.0
7.25
1.40
3.42
48.3 (in 1
1/2)
1.0
4.16
1.67
1.72
1.2
4.93
1.67
2.04
1.5
6.04
1.66
2.50
2.0
7.81
1.64
3.23
2.5
9.46
1.62
3.92
3.0
11.00
1.61
4.55
4.0
13.8
1.57
5.70
60.3 (in 2)
1.0
8.19
2.10
2.72
1.2
9.73
2.09
3.23
1.5
11.98
2.08
3.97
2.0
15.58
2.06
5.17
2.5
18.99
2.05
6.30
3.0
22.22
2.03
7.37
4.0
28.2
2.00
9.34
76.1 (in 2
1/2)
1.5
24.46
2.64
6.43
2.0
32
2.62
8.40
2.5
39.19
2.60
10.30
3.0
46.10
2.59
12.11
4.0
59.1
2.55
15.5
5.0
70.9
2.52
18.6
88.9 (in 3)
1.5
39.34
3.09
8.85
2.0
51.6
3.07
11.60
2.5
63.37
3.06
14.26
3.0
74.76
3.04
16.82
4.0
96.3
3.00
21.7
5.0
116
2.97
26.2
101.6 (in 3
1/2)
2.0
77.63
3.52
15.28
2.5
95.61
3.50
18.82
3.0
113.04
3.49
22.25
4.0
146
3.45
28.80
5.0
177
3.42
34.9
6.0
206.68
3.39
40.68
114.3 (in 4)
2.0
111
3.97
19.5
2.5
137.26
3.95
24.02
3.0
162.55
3.94
28.44
4.0
211
3.90
36.9
5.0
257
3.87
45
6.0
300.21
3.83
52.53
139.7 (in 5)
2.5
253.63
4.85
36.31
3.0
301.09
4.83
43.11
4.0
393
4.80
56.2
5.0
481
4.77
68.80
6.0
564.26
4.73
80.78
168.3 (in 6)
3.0
532.28
5.85
63.25
4.0
697
5.81
82.88
5.0
856
5.78
102
6.0
1008.69
5.74
119.87
